Isolated Module, Conformal Coated DC DC Converter 4 Output 5V 12V 12V 5V 1.4A, 700mA, 700mA, 1.4A 18V - 75V Input
| Product Attribute | |
| Manufacturer | Bel Power Solutions |
| Type |
Isolated Module, Conformal Coated
|
|
Number of Outputs
|
4 |
|
Voltage - Input (Min)
|
18V |
|
Voltage - Input (Max)
|
75V |
|
Voltage - Output 1
|
5V |
|
Voltage - Output 2
|
12V |
|
Voltage - Output 3
|
12V |
|
Voltage - Output 4
|
5V |
|
Current - Output (Max)
|
1.4A, 700mA, 700mA, 1.4A
|
|
Power (Watts)
|
31 W
|
|
Voltage - Isolation
|
2.1 kV
|
|
Applications
|
ITE (Commercial), Railway
|
|
Features
|
OCP, OTP, OVP, SCP, UVLO
|
|
Operating Temperature
|
-40°C ~ 85°C
|
| Mounting Type | Through Hole |
|
Size / Dimension
|
3.00" L x 2.50" W x 0.41" H (76.2mm x 63.5mm x 10.5mm) |
| Datasheet | Datasheet |
